Features
CAS No.: | 7440-41-7 |
Linear Formula: | Be |
Material: | Pure Beryllium |
Purity: | ≥99% |
Appearance: | Silver-gray Metallic Solid |
Shape: | Round, Rectangle or Customized |
Thickness: | 0.02mm - 1.5mm |
Description of Beryllium Flat Products
Welcome to our product page with our Beryllium Flat Products. These products are designed to meet the exacting standards of different industrial applications. Beryllium is an important part of modern manufacturing because it is strong, light, and can conduct heat well.
Beryllium is very strong, but it can break easily, so it's great for tough situations. Beryllium has a higher melting point than other light metals like aluminum and magnesium, at 1278°C. This makes it good for things that need to withstand high temperatures.
In normal conditions, beryllium forms a protective layer of hard oxide (BeO) on its surface. This makes it very resistant to oxidation and corrosion from water or air. This ability to resist makes it last a long time and works well, even in tough environments.
In addition, beryllium is very good at transferring heat and is not magnetic. This makes it very important for things that need to work well with electromagnetic fields. Beryllium is a metal that can be used in many different things like aerospace, military, medical imaging, diagnosis, and laser technology.
Even though beryllium has great qualities, it's important to know that it can be harmful and cause cancer. This means you need to be careful when handling it and follow safety rules in factories.
Our special Beryllium Flat Products are very strong, stable, and can do many different things. They are the best choice for applications that need light and strong materials. Use beryllium to make your projects better by being reliable and good at what you do. It's made to do more than you think it can do in tough situations.
Chemical Composition of Beryllium Flat Products
Element | Fe | Al | Si | Mg | Mn | BeO | Be2C |
Content (Max)/ % | 0.115 | 0.0068 | 0.0058 | 0.0021 | 0.0015 | 1 | 0.021 |
Specification of Beryllium Flat Products
Round:
Thickness (mm) | Diameter (mm) |
0.02 ~ 0.05 (tolerance: -/+ 0.005) | ≤ 50 (tolerance: +0/-0.2) |
0.05 ~ 0.1 (tolerance: -/+ 0.01) | ≤ 100 (tolerance: +0/-0.3) |
0.1 ~ 0.5 (tolerance: -/+ 0.02 ~ -/+ 0.03) | ≤ 100 (tolerance: +0/-0.3) |
0.5 ~ 1.5 (tolerance: -/+ 0.05 ~ -/+ 0.1) | ≤ 100 (tolerance: +0/-0.3) |
Rectangle:
Thickness (mm) | Width (mm) | Length (mm) |
0.02 ~ 0.05 (tolerance: -/+ 0.005) | ≤ 50 (tolerance: +0/-0.2) | ≤ 50 (tolerance: +0/-0.2) |
0.05 ~ 0.1 (tolerance: -/+ 0.01) | ≤ 100 (tolerance: +0/-0.3) | ≤ 100 (tolerance: +0/-0.3) |
0.1 ~ 0.5 (tolerance: -/+ 0.02 ~ -/+ 0.03) | ≤ 100 (tolerance: +0/-0.4) | ≤ 150 (tolerance: +0/-0.4) |
0.5 ~ 1.5 (tolerance: -/+ 0.05 ~ -/+ 0.1) | ≤ 100 (tolerance: +0/-0.45) | ≤ 200 (tolerance: +0/-0.45) |
Surface Condition
● Clean, flat without any cracks, scratches and black dots larger than 0.25mm diameter
● Slight airtight black dots (<0.25mm) and scratches are acceptable
● Edge maybe slightly oxidized by wire cut
Applications and Related Industries for Beryllium Flat Products
● Imaging equipment for Homeland Security
● High-resolution medical radiography
● Analytical equipment for blood, HIV, and other diseases
● Military fighter jets requiring speed and maneuverability
● Enhance surveillance and targeting systems in military helicopters
● Copper beryllium alloys in network tubes, rotors, and switches for military communications due to its high strength and electrical / thermal conductive properties
● Component in particle physics experiments
● Material in acoustic applications for its damping properties
● X-ray tubes and detectors required to monitor the flow of water, oil, and gas during well extraction
Chemical Identifiers
Linear Formula | Be |
MDL Number | MFCD00134032 |
EC No. | 231-150-7 |
Beilstein/Reaxys No. | N/A |
Pubchem CID | 5460467 |
SMILES | [Be] |
InchI Identifier | InChI=1S/Be |
InchI Key | ATBAMAFKBVZNFJ-UHFFFAOYSA-N |
Beryllium Flat Products Properties (Theoretical)
Molecular Weight | 9.01 |
Appearance | solid |
Melting Point | 1277 °C |
Boiling Point | 2970 °C |
Density | 1.848 g/cm3 |
Solubility in H2O | N/A |
Electrical Resistivity | 4.0 microhm-cm @ 20 oC |
Electronegativity | 1.5 Paulings |
Heat of Fusion | 2.8 Cal/gm mole |
Heat of Vaporization | 73.9 K-cal/gm atom at 2467 °C |
Poisson's Ratio | 0.032 |
Specific Heat | 0.436 Cal/g/K @ 25 °C |
Tensile Strength | N/A |
Thermal Conductivity | 2.01 W/cm/K @ 298.2 K |
Thermal Expansion | (25 °C) 11.3 µm·m-1·K-1 |
Vickers Hardness | 1670 MPa |
Young's Modulus | 287 GPa |
Beryllium Flat Products Health & Safety Information
Signal Word | Danger |
Hazard Statements | H301-H315-H317-H319-H330-H335-H350i-H372 |
Hazard Codes | T+ |
Precautionary Statements | P201-P260-P280-P284-P301 + P310 + P330-P304 + P340 + P310 |
Flash Point | Not applicable |
Risk Codes | 49-25-26-36/37/38-43-48/23 |
Safety Statements | 53-45 |
RTECS Number | DS1750000 |
Transport Information | UN 1567 6.1/PG 2 |
WGK Germany | 3 |
GHS Pictograms | GHS02 Flame
GHS08 Health Hazard
GHS06 Skull and Crossbones
|
