Zirconium Flange

Material: R60702, R60704, R60705

Send Inquiry

Add To Inquiry

Features

Material:	R60702, R60704, R60705
Purity:	95%~99.5%
Standard:	ASTM B551
Appearance:	Silvery Solid
Size:	Thickness 0.5-50mm, Diameter <1000mm

Zirconium Flange Description

SSC specializes in producing high purity uniform shaped zirconium flanges. Flanges are often used to connect pipes or steam cylinders. SSC offers custom flanges with annealed or hard tempers and will meet most of the common Mil spec or ASTM standards. Most flanges have external ridges with circular holes so screws can provide extra safety and strength. In addition to standard alloys, SSC also specializes in corrosion resistant alloys, high temperature applications, and custom shapes and forms, including custom hole drill locations and threading.

Zirconium flanges are most beneficial when used is in hydrochloric acid processes with temperatures above the boiling point and in the absence of oxidizing impurities. In sulfuric acid, zirconium flanges are resistant to temperatures well above boiling and at acid concentrations up to 70%. Zirconium can be used in all concentrations of nitric acid up to 90% and temperatures up to 200℃. Zirconium is also resistant to most organic media and is considered one of the most corrosion resistant material in virtually all acetic acid solutions.

Though aeration does not affect the resistance of zirconium flanges, even small amounts of oxidizing media such as ferric or cupric chlorides will greatly decrease its corrosion resistance. In addition, acid in the presence of oxidizing halide contaminants and can accelerate the rate of attack on zirconium flanges even at low concentrations. Use of zirconium flanges in the presence of fluoride ions is also not recommended, even at low concentrations.

Standard Zirconium Flange Types

● Blind Flange

● Weld Neck Flange

● Long Weld Neck Flange

● Slip on Flange

● Socket Weld Flange

● Lap Joint Flange

● Ring Joint Flange

● Spectacle Blind Flange

Chemical Composition

	Sn	Fe	Cr	Ni	Hf	Nb	Zn+Hf
Zr 702	/	<0.05%	<0.05%	/	1~2.5%	/	~99.5%
Zr 704	1~2%	0.1~0.2%	0.1~0.2%	/	<4.5%	/	~97.5%
Zr 705	1~2%	<0.05%	<0.01%	/	<4.5%	2~3%	~95.5%

Physical Properties

Material	State	Rm(≥)/MPa	Rp0.2(Pa	A50mm(≥)/%
Zirconium 702 (UNS R60702)	Annealed	379	207	16
Zirconium 704 (UNS R60704)	Annealed	413	241	14
Zirconium 705 (UNS R60705)	Annealed	552	379	16
