Titanium Zirconium Molybdenum

Titanium Zirconium Molybdenum (TZM) is a strong metal alloy that can resist heat and work well. It has 0.5% titanium, 0.08% zirconium, and 0.01% carbon. The rest of it is molybdenum. Titanium and zirconium improve the alloy's strength, toughness, and creep resistance, while carbon improves its high-temperature performance.

Features:

● High strength and toughness at high temperatures

● Excellent creep resistance

● Low thermal expansion coefficient

● High thermal conductivity

● Good corrosion resistance

● High melting point (2610°C)

● Good weldability and machinability

Grades:

TZM is available in different grades, including:

● TZM 364: This grade contains 0.5% titanium, 0.08% zirconium, and 0.01% carbon.

● TZM 365: This grade contains 0.5% titanium, 0.08% zirconium, and 0.02% carbon.

● TZM 366: This grade contains 0.5% titanium, 0.08% zirconium, and 0.04% carbon.

Forms:

TZM is available in various forms, including:

Bars:

● Diameter range: 0.2 inches to 4 inches (5mm to 100mm)

● Length range: 4 inches to 118 inches (100mm to 3000mm)

● Tolerance: +/- 0.004 inches to +/- 0.04 inches, depending on the diameter (+/- 0.1mm to +/- 1mm, depending on the diameter)

Sheets:

● Thickness range: 0.004 inches to 2 inches (0.1mm to 50mm)

● Width range: 4 inches to 39 inches (100mm to 1000mm)

● Length range: 4 inches to 79 inches (100mm to 2000mm)

● Tolerance: +/- 0.004 inches to +/- 0.04 inches, depending on the thickness and width (+/- 0.1mm to +/- 1mm, depending on the thickness and width)

Plates:

● Thickness range: 0.2 inches to 4 inches (5mm to 100mm)

● Width range: 4 inches to 39 inches (100mm to 1000mm)

● Length range: 4 inches to 118 inches (100mm to 3000mm)

● Tolerance: +/- 0.004 inches to +/- 0.04 inches, depending on the thickness and width (+/- 0.1mm to +/- 1mm, depending on the thickness and width)

Rods:

● Diameter range: 0.04 inches to 2 inches (1mm to 50mm)

● Length range: 4 inches to 118 inches (100mm to 3000mm)

● Tolerance: +/- 0.004 inches to +/- 0.04 inches, depending on the diameter (+/- 0.1mm to +/- 1mm, depending on the diameter)

Wires:

● Diameter range: 0.004 inches to 0.4 inches (0.1mm to 10mm)

● Length range: 4 inches to 118 inches (100mm to 3000mm)

● Tolerance: +/- 0.0002 inches to +/- 0.004 inches, depending on the diameter (+/- 0.005mm to +/- 0.1mm, depending on the diameter)

Production Method:

TZM is made by mixing the constituent elements in powder form and then heating them in a vacuum or hydrogen atmosphere. The TZM alloy is made by forging, rolling, or drawing it into the desired shape.

Applications & Related Industries:

TZM has several applications in various industries, including:

● Aerospace: TZM is used in the aerospace industry for engine parts, exhaust nozzles, and other things that need high temperatures.

● Defense: TZM is used in the defense industry for missile parts, rocket motor nozzles, and other high-stress applications.tions.

● Medical: TZM is used in the medical industry to make implants, surgical tools, and other high-strength applications.

● Electronics: TZM is used in the electronics industry for heat sinks, electrical contacts, and other high-temperature applications.

Health & Safety Information:

TZM is considered safe to use and handle. But like other metals, when you work with it or handle it, it can make dust or fumes that can be harmful if you breathe in them. So, it's important to be safe when handling or processing TZM. This means wearing protective gear like gloves, safety glasses, and a dust mask.

Our Advantages:

● High-quality TZM products

● Competitive pricing

● Timely delivery

● Excellent customer service

● Customized solutions to meet your specific needs

● Expert technical support

FAQs:

Q: What is the melting point of TZM?

A: The melting point of TZM is 2610°C.

Q: What is the difference between TZM and pure molybdenum?

A: TZM contains small amounts of titanium, zirconium, and carbon, which improve its strength, toughness, and creep resistance compared to pure molybdenum.

Q: Is TZM weldable?

A: Yes, TZM is weldable using traditional welding techniques, such as TIG or laser welding.

Q: What is the shelf life of TZM?

A: TZM has an indefinite shelf life if stored properly. However, it is recommended to keep it in a dry, cool, and clean environment to prevent any possible contamination or oxidation. It is also recommended to keep it in its original packaging or wrap it in protective material to prevent any damage during storage or transportation.
